SUITED FOR RESIDENTIAL
AND SEMI PUBLIC USE

Wallbox PRO Single Socket or with 6.5 Meter Cable

An intelligent, affordable and scalable charging solution that fits any location thanks to its attractive design and ease of installation.

The Single is suitable for professional, fleet and residential use.

Thanks to the compact form factor & flexible mounting – including wall mounting or pedestal solutions – our charger can be installed in every location. Contemporary single or double pedestals and appropriate anchors which are compatible with the rest of the product range are provided.

All Single Wallbox chargers are equipped for bidirectional charging with the necessary hardware already on board. Future software upgrades will enable Vehicle-to-Grid (V2G) functionality on your station with compatible cars. Please note that your EV must also support AC V2G technology for bidirectional charging to work.

Product brief

  • Ethernet, Wifi and 4G Modem Options.
  • ISO-15118 and OCPP 2.0.1 Certified.
  • MID Certified Meter.
  • Socket or 6.5 meter cable option.
  • AC V2G bi-directional charging capable (awaiting compliance testing).
  • Integration with Solar PV and battery systems (works like the Zappi).
  • Integration with Home Energy Management System (HEMS) supporting Modbus TCP/IP or RS485.
  • Dynamic Load Balancing across EV Charging, household appliances, and battery storage.
  • Lifespan 10 years or longer.
  • Time-of-Use Optimization: Charge when electricity rates are lower or when solar output is at its peak.
  • CT Clamps for monitoring building consumption.

SPECIFICATIONS

Kar Chargers V2H charging station — Enovates Specifications Artboard 3 Copy 2

Dimensions

248 x 426 x 120 (w/o shutter)
248 x 426 x 165 (with shutter)

Kar Chargers V2H charging station — Enovates Specifications Artboard 2

Charging mode

Mode 3 (IEC 61851-1 ed. 3)
ISO 15118

Kar Chargers V2H charging station — Enovates Specifications Artboard 3 Copy

Metering

MID certified meter

Kar Chargers V2H charging station — Enovates Specifications Artboard 3 Copy 3

Socket

AC–Type2 socket
Optional: Schuko, Shutter

Kar Chargers V2H charging station — Enovates Specifications Artboard 1

Connectivity

Bluetooth
Wifi (AP & Client)
Ethernet (WAN + LAN, router)
2G – 4G – LTE

Kar Chargers V2H charging station — Enovates Specifications Artboard 3

Load balancing

Supported via optional hardware

Fully customizable

The charger has a flexible enclosure approach, which can easily be rebranded or fully customized to match the customer’s identity.

Custom prints, RAL-colors and even the shape of the enclosure can be modified to make the charger stand out and make a visual impact.

DISCOVER THE POSSIBILITIES
Kar Chargers V2H charging station — Colormodes Singlewallbox2
Kar Chargers V2H charging station — Singlewallbox 8
Kar Chargers V2H charging station — Singlewallbox 1
Kar Chargers V2H charging station — Singlewallbox 6
Kar Chargers V2H charging station — Singlewallbox 7

Solar Power Integration

External Limit Device + My-Enovates App: You can also use our external limit device in combination with the My-Enovates user app to manage power settings and monitor energy usage, allowing you to charge your EV using solar energy when it’s available, reducing your reliance on grid electricity.

The My-Enovates user app provides a special feature called “grid-zero,” which allows you to charge your EV only when solar or other renewable energy is available, ensuring that your charging process is 100% powered by renewable sources.

Easy management and intelligent charging with My-Enovates User App

Available for both Android and iOS, our app connects effortlessly to your charging station(s).

Manage consumption, set power limits and oversee load balancing with ease.

This white-label application can be customized to meet your customer’s needs.

Kar Chargers V2H charging station — Application Nextgen

Our new charger is smart, connected and ready for the future by complying to the highest and newest Australian standards. The charger offers support for load shedding, load balancing & smart charging.

Where needed, the charger can be completed with additional options, based on the local needs & regulatory requirements. This way, the charger can be integrated in various eco-systems.
