eVolve Smart Bollard
The eVolve Smart Bollard is an advanced floor-mounted charging station with an aluminium and ABS plastic enclosure.
The station is fitted with two Type 2 sockets OR two Type 2 tethered cables. It has twin onboard Type B RCDs for protection against DC leakage. This is a legal requirement. The station can be connected to a local network via its Ethernet port or by a 4G modem to a mobile network.
The station is also available in a master/slave configuration suitable for clustered charging station installations where one station is used to command and control the other stations and act as a single communications gateway to the back end management and billing systems.
Scroll to the end of the page and download the technical specifications and manuals in PDF format.
Features include:
- Smart Technology enabled charging station for Public Access and Commercial Installation
- Dynamic load balancing using THOR
- User and Operator focus design and features
- Built-in embedded static load management
- One charging station serves two cars simultaneously
- Available in Single Phase (7kw) & Three Phase (22kw)
- Designed to be accessible by the disabled, complying with international standards regarding the height of connectors
| S | T | |
| General Specification | ||
| Phase Type: | Single Phase (1P) | Three Phase (3P) |
| Connection: | Type 2 (T2) | Type 2 (T2) |
| Number of Plugs: | 2 | 2 |
| Power Supply: | 230 Volts AC | 400 Volts AC |
| Max. Input Current: | 64 Amps | 64 Amps |
| Max. Input Power: | 14.8 kW | 44 kW |
| Socket/Cable: | Socket | Socket |
| Outlet A / B | ||
| Output Current: | 32 Amps / 32 Amps | 32 Amps / 32 Amps |
| Output Power: | 7.4kW / 7.4kW | 22 kW / 22 kW |
| Socket Type: | Type 2 Socket/ Type 2 Socket | Type 2 Socket/ Type 2 Socket |
| Optional
Accessories |
||
| 4G Modem (Latam/AU): | $480.32 (Ex) or $528.35 (Inc) | $480.32 (Ex) or $528.35 (Inc) |
| Customisation – labelling: | Please enquire for a quote. | Please enquire for a quote. |
| Tethered Cable (Pair): | Please enquire for a quote. | Please enquire for a quote. |
| Anti-Vandal Key: | $101.29 (Ex) or $111.42 (Inc) | $101.29 (Ex) or $111.42 (Inc) |
ALL ABOUT EVOLVE WALL BOX
The eVolve Smart T Wall Box can be either single phase (7kW) or three phase (22kW). It can be situated as 1 station per 2 parking spaces, with 1 or 2 sockets.
POWER SUPPLY
The output of kW can be dialled down via a software configuration change if the power supply is inadequate for the rating of the station. The output of kW can also be load balanced across 2 sockets.
MAIN FEATURES
- Optional Type A/B internal RCDS,
- On-board ethernet and 3G modem for networking,
- IP54/IK10 Rating and,
- Large enclosure for optional RCDs.
ALUMINIUM AND ABS PLASTIC STRUCTURE
The charger’s housing, aluminium and ABS plastic have been combined in a robust structural design that provides protection to both mechanical stress and severe environmental conditions, increasing the charger lifespan and avoiding its replacement in just a few years.
EVolve Smart - Wall Mounted/Bollard Mounted
Application
Designed to minimise the initial investment (CAPEX) and the operating expenses (OPEX) when several chargers are required, this
solution is a combination of a Master charger and a set of Slaves
controlled by this Master. The whole system works as if all the chargers had smart capabilities.
Suitable for private installations such as company fleets or communities with a single administrator, and also for public access environment such as shopping centers, car parks, airports and others.
Concept Design
It has the same exterior design concept as the acclaimed
eVolve Smart series, and in addition to featuring modern lines and robust
housing, harsh weather conditions and user-friendly operation have also
been considered.
Features:
- The Master charger is capable of balancing the available power based on the number of charge points in use.
- The Master can operate up to 8 Slaves (max. 18 charging points including the Master)
- A single modem in the Master unit can be
used for remote connection and back-office
system integration
